If you wish to use the digital inputs on the Nano IO Air please contact Faradite customer support on use the inputs on the Miniserver, Extension, Dimmer Extension, DI Extension you must wire in a star topology, and to use the inputs of the Nano DI Tree you must wire in a tree topology. Suitable Loxone devices that have 24V digital inputs include the Miniserver, Extension, Dimmer Extension, DI Extension and Nano DI Tree. There are multiple ways in which the TAP range of switches can be wired in to the Loxone system, but essentially the TAP Volt Free range uses 1 digital input per button. This fly lead option has terminals for connection to cat cables and a 1-wire chip means temperature sensing can be achieved by connecting to the Loxone 1-wire extension.
The Loxone - Star (Inc 1-wire) is intended for Loxone systems that are star wired back to a central location. The Loxone Nano DI Tree option provides a fly lead that allows for rapid connection of all switch outputs into the Loxone Nano DI Tree device. There are also a couple of choices of fly leads when using TAP Volt Free switches with Loxone. The TAP-5 provides 5 buttons and the TAP-1 provides a single button.
There are 2 varieties of TAP switches: the TAP-5 and the TAP-1. This pulse acts as an input into the Loxone system and can then be utilised in Loxone config to provide a nearly endless range of functionality, we will look at the range of functions later in this blog.
The Faradite TAP Volt Free switch plate range provides a volt free (dry contact) that pluses for the duration of the button press.
